Fluent configure pattern in Golang

Photo by Caspar Camille Rubin on Unsplash

In this post, I want to share a pattern that helps in configure/construct a service. You can see the final result code first for easier to get the context

package main

import (
	"time"

	"github.com/jkaveri/fluent-option/fluentcache"
)

func main() {
	connection := "localhost"
	password := "JA$2mAe%1@s5"
	db := 0
	readTimeout := 2 * time.Second
	writeTimeout := 2 * time.Second
	dialTimeout := 5 * time.Second

        // Configure redis cache fluent
	redisCache := fluentcache.NewRedisCache(
		fluentcache.UseStandalone(connection),
		fluentcache.WithDB(db),
		fluentcache.WithPassword(password),
		fluentcache.WithTimeoutPolicy(
			dialTimeout,
			readTimeout,
			writeTimeout,
		),
	)

	// set key
	_ = redisCache.Set("my_key", "my_value")
}

Problem

When design API in Golang I usually create a function that helps to configure the service.

// cache/cache.go
package cache

type RedisCache struct {
	connection string
	db         int
	password   string
}

// RedisCache create new redis cache
func NewRedisCache(connection, password string, db int) *RedisCache {
	return &RedisCache{
		connection: connection,
		password:   password,
		db:         db,
	}
}

func (*RedisCache) Set(key, value string) error {
	return nil
}

func (*RedisCache) Get(key string) (string, error) {
	return "", nil
}

I skipped some implementation detail to keep the code simple, you only need to focus the NewRedisCache function

Then I can init my RedisCache like this:

// main.go
package main

import "github.com/jkaveri/fluent-option/cache"

func main() {
	connection := "localhost"
	password := "JA$2mAe%1@s5"
	db := 0

	redisCache := cache.NewRedisCache(connection, password, 0)

	// set key
	_ = redisCache.Set("my_key", "my_value")
}

The configure looks good enough and I started to use that configure function in many places. Unfortunately, I was got a problem when I want to add more argument into the configure function because of I want to add more feature for my service, the problems are:

So we only have these options:

  • Add new arguments into existing function and update existing code. This option is worse because of that impact on the existing code. Furthermore, in case your API is the dependency of other packages and this option can is a breaking change

    // cachev2.go
    package cachev2

    import "time"

    type RedisCache struct {
        connection string
        db         int
        password   string

        maxRetries      int
        minRetryBackoff time.Duration
        maxRetryBackoff time.Duration
    }

    // RedisCache create new redis cache
    func NewRedisCache(
        connection, password string,
        db, maxRetries int,
        minRetryBackoff, maxRetryBackoff time.Duration,
    ) *RedisCache {

        return &RedisCache{
            connection:      connection,
            password:        password,
            db:              db,
            maxRetries:      maxRetries,
            minRetryBackoff: minRetryBackoff,
            maxRetryBackoff: maxRetryBackoff,
        }
    }

    func (*RedisCache) Set(key, value string) error {
        return nil
    }

    func (*RedisCache) Get(key string) (string, error) {
        return "", nil
    }

  • Create a new function with meaning name, creating a new function makes sense but what if we will need more arguments in future? Of course, you can say we need compliance with YAGNI, but sometimes if we have an option that more flexible so that the API more stable. In other words, in a future version of API, the API’s clients don’t struggle about the breaking changes

    package cachev3

    import "time"

    type RedisCache struct {
        connection string
        db         int
        password   string

        maxRetries      int
        minRetryBackoff time.Duration
        maxRetryBackoff time.Duration

        dialTimeout  time.Duration
        readTimeout  time.Duration
        writeTimeout time.Duration
    }

    // RedisCache create new redis cache
    func NewRedisCache(connection, password string, db int) *RedisCache {
        return &RedisCache{
            connection: connection,
            password:   password,
            db:         db,
        }
    }

    func NewRedisCacheWithRetryPolicy(
        connection, password string,
        db, maxRetries int,
        minRetryBackoff, maxRetryBackoff time.Duration,
    ) *RedisCache {
        rc := NewRedisCache(connection, password, db)

        rc.maxRetries = maxRetries
        rc.minRetryBackoff = minRetryBackoff
        rc.maxRetryBackoff = maxRetryBackoff
        return rc
    }

    func NewRedisCacheWithTimeoutPolicy(
        connection, password string,
        db, maxRetries int,
        dialTimeout, readTimeout, writeTimeout time.Duration,
    ) *RedisCache {
        rc := NewRedisCache(connection, password, db)
        rc.dialTimeout = dialTimeout
        rc.readTimeout = readTimeout
        rc.writeTimeout = writeTimeout
        return rc
    }

    func (*RedisCache) Set(key, value string) error {
        return nil
    }

    func (*RedisCache) Get(key string) (string, error) {
        return "", nil
    }


Two solutions above can be applied in some cases it is simple and easy for implementing but it doesn’t flexible because of when you add new arguments you need a new API signature.

Solution

The solution is the application of Closure and the High Order Function.

Please read the code then I will explain more about the pattern

fluentcache/cache.go

package fluentcache

import (
	"context"
	"crypto/tls"
	"net"
	"time"

	"github.com/go-redis/redis"
)

type ConfigureFunc = func(redisCache *RedisCache)

type DialerFunc = func(
	ctx context.Context,
	network,
	addr string,
) (net.Conn, error)

type OnConnectFunc = func(conn *redis.Conn) error

type RedisCache struct {
	sentinel   bool
	connection string
	db         int
	password   string

	sentinelAddrs    []string
	masterName       string
	sentinelPassword string

	dialer          DialerFunc
	onConnect       OnConnectFunc
	maxRetries      int
	minRetryBackoff time.Duration
	maxRetryBackoff time.Duration

	dialTimeout  time.Duration
	readTimeout  time.Duration
	writeTimeout time.Duration

	poolSize           int
	minIdleConns       int
	maxConnAge         time.Duration
	poolTimeout        time.Duration
	idleTimeout        time.Duration
	idleCheckFrequency time.Duration

	tLsConfig *tls.Config
}

// RedisCache create new redis cache
func NewRedisCache(configures ...ConfigureFunc) *RedisCache {
	var rc RedisCache
	for _, configure := range configures {
		configure(&rc)
	}
	return &rc
}

func (*RedisCache) Set(key, value string) error {
	return nil
}

func (*RedisCache) Get(key string) (string, error) {
	return "", nil
}

fluentcache/configure.go

package fluentcache

import (
	"crypto/tls"
	"time"
)

func UseStandalone(connection string) ConfigureFunc {
	return func(rc *RedisCache) {
		rc.sentinel = false
		rc.connection = connection
	}
}

func UseSentinelRedis(
	masterName string,
	sentinelAddrs []string,
	sentinelPassword string,
) ConfigureFunc {
	return func(rc *RedisCache) {
		rc.sentinel = true
		rc.masterName = masterName
		rc.sentinelAddrs = sentinelAddrs
		rc.sentinelPassword = sentinelPassword
	}
}

func WithPassword(password string) ConfigureFunc {
	return func(rc *RedisCache) {
		rc.password = password
	}
}

func WithDB(db int) ConfigureFunc {
	return func(rc *RedisCache) {
		rc.db = db
	}
}

func WithDialer(dialer DialerFunc) ConfigureFunc {
	return func(rc *RedisCache) {
		rc.dialer = dialer
	}
}

func OnConnect(onConnectFunc OnConnectFunc) ConfigureFunc {
	return func(rc *RedisCache) {
		rc.onConnect = onConnectFunc
	}
}

func WithRetryPolicy(
	maxRetries int,
	minRetryBackoff, maxRetryBackoff time.Duration,
) ConfigureFunc {
	return func(rc *RedisCache) {
		rc.maxRetries = maxRetries
		rc.minRetryBackoff = minRetryBackoff
		rc.maxRetryBackoff = maxRetryBackoff
	}
}

func WithTimeoutPolicy(
	dialTimeout, readTimeout, writeTimeout time.Duration,
) ConfigureFunc {
	return func(rc *RedisCache) {
		rc.dialTimeout = dialTimeout
		rc.readTimeout = readTimeout
		rc.writeTimeout = writeTimeout
	}
}

func WithConnectionPoolPolicy(
	poolSize, minIdleConns int,
	maxConnAge, poolTimeout, idleTimeout, idleCheckFrequency time.Duration,
) ConfigureFunc {
	return func(rc *RedisCache) {
		rc.poolSize = poolSize
		rc.minIdleConns = minIdleConns
		rc.maxConnAge = maxConnAge
		rc.poolTimeout = poolTimeout
		rc.idleTimeout = idleTimeout
		rc.idleCheckFrequency = idleCheckFrequency
	}
}

func WithTLSOptions(tlsConfig *tls.Config) ConfigureFunc {
	return func(rc *RedisCache) {
		rc.tLsConfig = tlsConfig
	}
}

As you can see, instead of using many arguments with different types. I only use 1 type is ConfigureFunc with Variadic function.

The ConfigureFunc will take the RedisCache pointer as an argument and then ConfigureFunc can set the value for the RedisCache pointer.

With this pattern, my job is defining the fluent configure functions you can see them in fluentcache/configure.go. My fluent configure functions will return the ConfigureFunc (High Order Function) and the returned ConfigureFunc can access the argument of outer function because of Go has support Closure.

With this pattern you can have some advantages:

  • Configure service fluently configure fluently
  • Flexible API and reduce breaking changes flexible API and reduce breaking changes
  • Can be used for optional argument with a default value

Tradeoff

This pattern is good but it has some trade off

  • The configure function will not clear with API consumer. I need document it carefully to help API consumer know what API supports
  • ConfigureFunc is stateful so it isn’t good if I add new ConfigureFunc without understanding previous ConfigureFunc.

Conclusion

The fluent configure pattern is good but it requires extras effort to implement. So I don’t’ use always, I only use it when I see the API may be changed in the future. For example, I design an API for logging and I know I will change the way I log in future then I will use the fluent configure pattern

p.s: This pattern doesn’t new you can see this pattern in some popular package.

Using PowerShell profile as to speed up your development process

I am a developer with a background in .NET. I work mostly on Windows (sometimes I work on MAC but not often). I have used MAC as the main development environment for the last six months and honestly, I like working on MAC much more than Windows and one of the reasons is that MACs terminal is really powerful and it is even cooler when you use ZSH (I will talk about this in another post).

Now I’m using Windows to write this post, just because I’m working on a project that uses .NET technology. (Unfortunately, I don’t use Visual Studio for MAC at all.)

Problem

When using a MAC I have some alias (or functions) to speed my development process.

For example, when using GIT I usually update master branch then merge code from the master branch back to a feature branch. In MAC I only type 1 command:

gup master && git merge master
# help me update master branch then switch back


In the code block below the gup command is a function that was added in ~/.bash_profile and it looks like below:


function gup () {
  c=$(git rev-parse --abbrev-ref HEAD)
  git checkout "$1"
  git pull
  git checkout "$c"
}

When switching back to Windows development I felt uncomfortable like missing my pocket knife.

Solutions

Fortunately, PowerShell has a feature like ~/.bash_profile which is called “PowerShell Profile”. You can read more about “PowerShell Profile” here.

The PowerShell profile basically is a .ps1 file which will be loaded every time you open a PowerShell engine. There are serval profile files and based on your needs you can choose what profile file you want to add to your utility scripts.

DescriptionPath
All Users, All Hosts $PsHome\Profile.ps1
All Users, Current Host $PsHome\Microsoft.PowerShell_profile.ps1
Current User, All Hosts $Home\[My ]Documents\PowerShell\Profile.ps1
Current user, Current Host $Home\[My ]Documents\PowerShell

Host is the interface that the Windows PowerShell engine uses to communicate with the user. For example, the host specifies how prompts are handled between Windows PowerShell and the use.

more

For example, PowerShell.exe in a host and PowerShell in the Visual Studio Code (VSCode) is a different one.

If you encounter an issue that you cannot access some functions in VSCode while you can access it in the PowerShell.exe, you might add the functions in PowerShell.exe host.

Bonus

Below are some utility functions that I’m using:


# GIT: publish local branch to remote
function gpo() {
    git push origin --set-upstream $(git rev-parse --abbrev-ref HEAD)
}

# GIT: update a branch then switch back to the current branch
function gup () {

    $c=$(git rev-parse --abbrev-ref HEAD)

    git checkout "$1"

    git pull

    git checkout "$c"
}

# GIT: quick command to help your code and push to remote
function gsave() {
    git add .

    $msg=$args[0]

    if ([string]::IsNullOrEmpty($msg)) {
        $msg = "save code"
    }

    git commit -m "$msg"

    gpo
}

# GIT: git fetch from origin with prune flag
function gfo() {
    git fetch origin --prune
}

# GIT: Alias for git commit -m
function gcom() {
    git commit -m $args[0]
}

# GIT: Create directory and cd into it
function mkd {
    New-Item -Path $args[0] -ItemType Directory -Force -Out
    Set-Location $args[0]
}

Conclusion

I’m a lazy developer so I need to reduce some repeated task and PowerShell profile is one of the most useful tools.

If you have used PowerShell profile or PowerShell script file to speed up your development process, please share your utility functions in the comment below.

P.s: the banner of this post I borrowed from https://medium.com/@jsrice7391/using-vsts-for-your-companys-private-powershell-library-e333b15d58c8 ๐Ÿ˜‰

Type-checking ImmutableJS with TypeScript

When developing a React application using state management system like Redux, you usually use Immutable.JS to make your state not mutable. If you are using VanillaJS you will feel comfortable with the magic string prop name like: `get(“field_name”)` and `set(“field_name”, value)`. However, it is awkward when you are using TypeScript because you will loose the type-checking.

Continue reading

Unable to start IIS Application Pool after upgrade to windows 10 Fall Creator

Problem #

After upgrading to the Windows 10 Fall Creator. I got the message below when I tried to access my IIS site


Service Unavailable HTTP Error 503. The service is unavailable.

and you may see the error below in windows event viewer:

error log

Solution #

To solve the problem you can follow these steps:

  1. Open a Windows PowerShell window by using the Run as administrator option.
  2. Run these commands:
Stop-Service -Force WAS
Remove-Item -Recurse -Force C:\inetpub\temp\appPools\*
Start-Service W3SVC

For more detail, please refer to this link: https://goo.gl/uH8o9n

Improve Performance by caching layer

Intro #

Performance is one of the hottest topics in the software development industry. In this post, I would like to share my experience when optimizing a CRM system which serves ~1k requests/second.

Problem #

Imagine, a CRM system has ~1000 user preferences (e.g. time zone, date format, currency,…), those user preferences are stored in a SQL database, and it will be loaded every single click to reflect the preference of the user. If your web app serves ~1K requests/second, it means there are ~1M requests to the DB per second (in the worst case). At this point, you can see we can improve the performance of the app by reducing the number of requests to the database and it’s time for the caching layer to shine!.

Breaking down the problem #

We break down into smaller problems:

  1. P1: In the current system, we have a helper class, let’s say UserPreference. It exposed 2 methods: string Get(userId, key) and void Set(userId, key, value). These methods will go to the database to get or set data. How to reduce code rewriting to reduce risks? What is the backup plan if the changes cause problem in production?
  2. P2: The UserPreference class was shared to many projects (Asp.net web form, Asp.net Web API, Window service, Load balancer nodes…). So, data consistency in distributed environment is a problem.
  3. P3: In the future if we need to cache more things (Big query result, File content,…). The cache system should be easy to extend.

Solution #

To solve the problem, I create CacheBucket pattern. See the class diagram below:

cache bucket pattern

Imagine, a bucket can contain values (water, sand, oil,…) and it can contain another Bucket. This is the core concept of the CacheBucket pattern.

The CacheBucket pattern includes:

  • ICacheStorage: An interface which take responsibility to get or set cache data from a storage. (Memory, Redis, file…)
  • Client$: A place which uses the pattern.
  • CacheBucket: Manage inner buckets and cache values, it depends on ICacheStorage.
  • UserPreferenceCacheBucket and BigQueryCacheBucket: Inherit the CacheBucket class for specific ICacheStorage. In detail, the UserPreferenceCacheBucket will use InMemoryCacheStorage. On another hand, the BigQueryCacheBucket will use the RedisCacheStorage.
  • InMemoryCacheStorage and RedisCacheStorage: Implementations of the ICacheBucket

Ok! Now we will see how the CacheBucket pattern can solve the problem.

First, the CacheBucket class handled all logic about caching management so we just update small code change in the UserPreference class for adding caching into the system. For the backup solution we just add a flag (configurable value) which helps to detect if the caching system is enabled or not. In case there is a problem in production we can switch back to the old code by changing the value of the flag. So, P1 is solved.

Second, to solve the concurrency problem, we should use a centralized cache server such as Redis. Fortunately, with the CacheBucket pattern we can easily change the cache storage by implementing the ICacheStorage interface. So, P2 is solved.

Therefore, the CacheBucket pattern is very easy to extend. For example, if you want to cache the reporting result, all you need is to extend the CacheBucket class.

Benchmark #

To do the benchmark, I have created an example project. We can switch between enabling or disabling the cache. So, we can do benchmark the latency of the web application while enable/disabled the caching layer.

For the tool, I used the WRK (a HTTP Benchmarking tool) to simulate 200 connections (users) with this command:

wrk -t2 -c200 -d60s --timeout 3s http://cachebucket.com:5000/\?user_id\=1

The result #

When the caching layer is enabled, the latency is 465.46 ms and the web app can response 481.27 requests/sec. On another hand, the latency is 658.68 ms and 305.73 requests/sec when the caching layer is disabled. You can see more details below:

Without cache
caching layer disabled
With cache
caching layer enabled

How to use CacheBucket pattern: #

Install package #

To use CacheBucket pattern you need to install packages from NuGet.

There are 3 packages:

  1. CacheBucket.Core contains the core of cache bucket. In theory, you can use cache bucket pattern with this package only. However, for more convenience, you can consider other 2 packages below.
  2. CacheBucket.InMemory contains an InMemoryCacheStorage which is an implementation of ICacheStorage to store cache data in memory.
  3. CacheBucket.Factory contains some helper classes and extension methods that help to create a CacheBucket inline code. e.g: CacheBucketFactory.Create("UserPreference:1")

This is an example command to install CacheBucket.Core in “Package Management Tools”

Install-Package CacheBucket.Core #replace CacheBucket.Core by another package name to install another package.

or if you prefer the dotnet command:

dotnet add package CacheBucket.Core

Sample code #

Because of the CacheBucket class is open for extending you can create a derived class as the sample code below:

using CB.Core;
using CB.InMemory;

namespace WebApplication.Helpers {
    public class UserPreferenceCacheBucket : CacheBucket {
        public const string NAME = "UserPreference";

        public UserPreferenceCacheBucket (InMemoryCacheStorage cacheStorage) : base (NAME, cacheStorage) { }
    }
}

And then you can inject the UserPreferenceCacheBucket class into a client:

using CB.Core;
using WebApplication.Data;
using WebApplication.Data.Models;

namespace WebApplication.Helpers {
    public class UserPreferenceHelper {
        private readonly UserPreferenceCacheBucket _cacheBucket;
        private readonly ApplicationDbContext _dbContext;

        // The UserPrefrenceCacheBucket can be inject by IoC container.
        public UserPreferenceHelper (UserPreferenceCacheBucket cacheBucket, ApplicationDbContext dbContext) {
            _cacheBucket = cacheBucket;
            _dbContext = dbContext;
        }

        public string Get (int userId, string key) {
            CacheBucket userBucket = null;
            if (MvcApplication.EnableCacheBucket) {
                userBucket = _cacheBucket.In (userId.ToString ());

                // get cache value.
                var cacheValue = userBucket.GetValue (key);

                if (string.IsNullOrEmpty (cacheValue) == false) {
                    return cacheValue;
                }
            }

            // get db value.
            UserPreference userPreference = GetUserPreference (userId, key);

            if (userPreference == null) {
                return null;
            }

            // set into cache.
            userBucket?.SetValue (key, userPreference.Value);

            return userPreference.Value;
        }

        /// ...
    }
}

Conclusion #

Overall, the caching layer is simple and easy to apply but effective. You don’t need to use CacheBucket to apply caching layer, you can apply the caching pattern in your own way as long as it is the most effective way for your situation.

This is my personal experience. If you have any better way, please share it on the comments, and we can discuss later๐Ÿ˜œ
